MP-Force L2-7022

Efficient Solar Storage & High PERFORMANCE

Flexible Modular Expansion

• Modular battery design with 3.55 kWh per module
• Configurable system capacity from 7.1 kWh to 14.2 kWh
• Stackable structure enables quick installation without complex wiring
• High 90 % depth of discharge (DoD) for more usable energy

Benefits:

• Flexible system expansion
• Higher usable energy capacity
• Easy system maintenance and upgrade

Reliable Backup & Continuous Power

Stable Home Backup Energy

• 48 V low-voltage battery system for residential applications
• Built-in Battery Management System (BMS) for intelligent protection
• Long cycle life 6000+ cycles
• Designed lifespan 15+ years

Advantages:

• Reliable home backup power
• Long-term stable performance
• Safe residential operation

Intelligent Management & Connectivity

Smart Battery Control

• Integrated intelligent BMS control module
• Supports CAN & RS485 communication
• Compatible with major inverter brands
• Intelligent charge and discharge management

Benefits:

• Real-time system monitoring
• Smart energy optimization
• Wide inverter compatibility

Durable & Safe Design

Engineered for Long-Term Use

• LiFePO? battery technology for enhanced safety
• IP55 protection rating for indoor installation
• Plug-and-play stackable structure
• Compact and space-saving design

Advantages:

• High safety battery chemistry
• Durable and reliable operation
• Easy installation and maintenance

Why Choose China Moneypro Force-L2?

• Modular Design: 3.55 kWh per module
• Flexible Expansion: 7.1 kWh ?C 14.2 kWh system capacity
• Long Lifespan: 6000+ cycles & 15+ years
• Safe Battery Technology: LiFePO? chemistry
• Easy Installation: Stackable plug-and-play structure

Key Specifications

• Battery Type: LiFePO?
• Nominal Voltage: 48 V
• Module Capacity: 3.55 kWh
• System Capacity: 7.1 kWh ?C 14.2 kWh
• Depth of Discharge: 90 %
• Cycle Life: 6000+ cycles
• Protection Rating: IP55
• Communication: CAN / RS485
• Operating Temperature: 0 ??C ~ 50 ??C
• Design Life: 15+ years
• Installation: Floor-standing / Stackable

Typical Applications

• Residential Solar Storage
• Home Backup Power
• Self-Consumption Optimization
• Small Commercial Energy Storage
• Off-Grid Solar Systems

FAQ ?C Common Questions

Q1: What capacity options are available?
China Moneypro Force-L2 supports 7.1 kWh to 14.2 kWh modular configurations.

Q2: Can the system be expanded later?
Yes, the system uses stackable modules allowing flexible expansion.

Q3: What battery technology is used?
The system uses LiFePO? battery technology for safety and long life.

Q4: Is the system suitable for residential use?
Yes, the 48 V low-voltage design is ideal for residential applications.

Q5: What protection rating does the system have?
The system features IP55 protection for reliable indoor installation.
