MP-EV Charger-2577

MP-EV Charger-2577

The China Moneypro SMILE‑EVCT11 is a compact and feature‑rich AC electric vehicle (EV) charger designed for residential and light commercial charging scenarios. It supports intelligent charging modes, smart connectivity, and seamless integration with PV and energy storage systems to enable higher self‑consumption of renewable energy and flexible charging control.

Category:

Share your love

Intelligent, Efficient & Solar‑Ready EV Charging

The China Moneypro SMILE‑EVCT11 is a compact and feature‑rich AC electric vehicle (EV) charger designed for residential and light commercial charging scenarios. It supports intelligent charging modes, smart connectivity, and seamless integration with PV and energy storage systems to enable higher self‑consumption of renewable energy and flexible charging control.

Flexible Charging & Smart Power Use

Up to 11 kW AC Charging

  • Delivers up to 11 kW charging power to support faster daily EV charging sessions.

  • Single‑phase AC charging at 400 V (L+N+PE) and 16 A rated current for efficient energy transfer.

  • Works with Type 2 socket for broad EV compatibility.

Benefits:

  • Higher charging rates for daily commuting vehicles.

  • Works with most common EVs in global markets.

Smart Charge Modes & Connectivity

Intelligent & Green Charging

  • Multiple charging modes: Green mode (priority renewable energy), Fast mode, and ECO mode optimize charging behavior.

  • APP smart control and remote management for scheduling, monitoring, and configuration.

  • Supports OCPP 1.6 JSON protocol for integration with energy management and cloud platforms.

Advantages:

  • Charge EVs using excess solar or storage first to maximize self‑consumption.

  • Remote insights and control for convenient operation.

Durable Build & Safety Protections

Designed for Everyday Use

  • IP65 protection rating ensures resistance against dust and water jets for outdoor or indoor installations.

  • Integrated 6 mA DC residual current detection (RCD) and electrical protections (overcurrent, over‑temperature).

  • RFID access control and secure authentication add usage control options.

Benefits:

  • Reliable performance in varied environmental conditions.

  • Enhanced safety for users and connected vehicles.

Easy Installation & User‑Friendly Design

Plug‑and‑Play Setup

  • Compact and lightweight design (~3 kg) allows easy wall installation.

  • Long 7 m Type 2 charging cable (external) simplifies parking placement.

  • LED indicators provide intuitive status feedback.

Advantages:

  • Quick installation and setup with minimal effort.

  • Flexible placement with extended cable reach.

Why Choose China Moneypro SMILE‑EVCT11?

  • High AC Charging Output: Up to 11 kW supports faster EV charging.

  • Smart Charging Modes: Multiple optimized charging strategies.

  • Robust Safety: Comprehensive protections with residual current detection.

  • IP65 Weather Resistance: Suitable for indoor/outdoor installations.

  • Connectivity & Control: APP and OCPP management for flexible system integration.

Key Specifications

  • Model Name: SMILE‑EVCT11 (China Moneypro branded)

  • Rated AC Power: 11 kW maximum

  • AC Rated Voltage: 400 V (L+N+PE)

  • Rated & Max Current: 16 A

  • Charging Interface: Type 2 socket

  • Protection Rating: IP65

  • Safety Features: RCD 6 mA DC + overcurrent/over‑temp protections

  • Communication: OCPP 1.6 JSON, Wi‑Fi/AP mode, RS485 support

  • Charging Cable: 7 m external Type 2 charging cable

  • Dimensions: ~340 × 250 × 110 mm (H×W×D)

  • Weight: ~3 kg

  • Operating Temp.: –30 °C to +50 °C

Typical Applications

  • Home EV Charging: Daily charging for residential electric vehicles.

  • Solar + Storage Integrated Charging: Use solar and battery generation to charge EVs.

  • Workplace & Semi‑Public Sites: Flexible AC charging for employees or visitors.

  • Smart Energy Ecosystems: Combined monitoring, scheduling, and energy management platforms.

FAQ – Common Questions

Q1: What charging power does SMILE‑EVCT11 support?
It supports up to 11 kW AC charging, suitable for most residential and light commercial EV charging needs.

Q2: Is this charger suitable for outdoor installation?
Yes — with IP65 protection, it is built to withstand rain and dust for outdoor usage.

Q3: How can I control or monitor the charger?
Remote control and monitoring are available via the associated APP and OCPP 1.6 cloud integration.

Q4: Does it support solar or battery priority charging?
Yes — it offers modes that prioritize solar or storage energy for EV charging to maximize green usage.

Q5: What connector type does it use?
It uses a Type 2 charging interface, widely compatible with global EVs.

Specifications

Parameter Specification
Model SMILE‑G3‑EVCT11
Dimensions (W × H × D) 250 × 142 × 340 mm
Weight 3 kg
Operating temperature ‑30 °C ~ 50 °C
Relative humidity 15% ~ 90% (No condensation)
Operating altitude < 2000 m
Warranty 2 Years Product Warranty
Compatible energy storage systems SMILE‑S6‑HV, SMILE‑T10‑HV, SMILE‑G3‑S3.6/S5/B5, SMILE‑G3‑T4/T6/T8/T10, SMILE‑G3‑T12/T15/T20
Input – AC Rated Voltage 400 V, 3P+N+PE
Rated current 16 A
Frequency 50 / 60 Hz
Output – AC Output Voltage 400 V
Max. current 16 A
Rated power 11000 W
Charger connector Type 2 Socket
Cable length External 7 m Type 2 ‑ Type 2 charging cable
Communication – OCPP OCPP 1.6 Json (using WiFi AP mode settings)
Communication – EMS RS485
Certification – Safety CE, EN 62133
Protection – RCD 6 mA DC
IP degree IP65 (depends on local policy)
