MP-SGD50 Low Voltage Motor Driver-7766

Reliable, High‑Power & Flexible Motor Drive System

The China Moneypro SGD Series is a family of medium‑voltage motor drivers engineered to meet the demanding performance, reliability, and flexibility needs of heavy industrial and wind power drivetrain applications. Designed with advanced drive control, multi‑motor support, and scalable configurations, the SGD Series ensures precise motor control, robust protection, and high efficiency across diverse factory, energy, and automation environments.

Powerful Motor Control & Multi‑Mode Compatibility

High‑Performance Drive Technology

• The SGD80 Series offers medium‑voltage motor driving with 8 MVA–14 MVA capacity per unit, supporting parallel operation for expanded system capability.

• PWM rectifier units provide near‑unity power factor and bi‑directional energy flow with minimal harmonic distortion — delivering high control efficiency.

• The SGD100 Series introduces cascaded multilevel conversion technology for excellent input/output harmonic performance and adaptable motor control methods.

• Compatible with permanent magnet synchronous motors (PMSM), asynchronous motors, doubly fed motors, and electro‑excited synchronous motors for broad application coverage.

Benefits:

• Precise speed and torque regulation for heavy industrial drives.

• Flexible drive strategies including V/F control, open‑loop and closed‑loop vector control.

Scalable & Configurable Architecture

Built to Grow with Your System

• Parallel expansion support allows multiple SGD units to work together for higher combined drive capacity and redundancy when needed.

• Modular design simplifies system integration and on‑site configuration, enabling tailored setups for diverse industrial environments.

• Optional bypass cabinets (manual/automatic) enhance system maintainability and safety.

Advantages:

• Expands seamlessly with increasing power demands without costly redesign.

• High flexibility for future technology upgrades and maintenance.

Robust Protection & Control Features

Designed for Industrial Reliability

• Online fault diagnosis and direct protection mechanisms detect and isolate issues such as overcurrent, thermal overload, and control faults.

• High efficiency drive stages support full power energy bi‑directional flow with minimal loss.

• Multiple control modes like vector control (sensorless or with speed sensor) and constant frequency control enable adaptable operation across load profiles.

Benefits:

• Enhanced drive system uptime with built‑in protection and diagnostics.

• Reduced mechanical stress on motors and connected equipment.

Why Choose China Moneypro SGD Series?

• High Capacity & Scalability: Supports large motor drives and parallel operation for expanded capacity.

• Multi‑Motor Compatibility: Works with various motor types from PMSM to asynchronous and doubly fed machines.

• High Efficiency Drive: Bi‑directional energy flow and unit power factor boost system performance.

• Flexible Control: Offers multiple control strategies for optimized speed, torque and power traceability.

• Robust Protection & Diagnostics: Reduces downtime with online fault diagnosis and effective protections.

Typical Applications

• Industrial Motor Drives: High‑power pumps, compressors and conveyors in manufacturing.

• Wind Power Turbine Drives: Medium‑voltage wind turbine yaw or pitch motor and drivetrain motor control.

• Pumping Stations & Water Treatment: High reliability motor operation for continuous service.

• Mining & Heavy Industry: Drives for mills, crushers, and hoist systems.

FAQ – Common Questions

Q1: What motor types does the SGD Series support?
China Moneypro SGD drivers are compatible with permanent magnet synchronous motors, asynchronous motors, doubly fed motors, and electro‑excited synchronous motors — covering most medium‑voltage industrial drive needs.

Q2: Can SGD units be used in parallel for higher capacity?
Yes — the SGD Series supports parallel operation of multiple units to scale drive capacity as system demand grows.

Q3: What control methods are available?
The drivers support V/F control, sensorless vector control (OLVC), and speed sensor vector control (CLVC) to adapt to various dynamic load requirements.

Q4: Do these motor drivers have built‑in protection features?
Yes — the SGD Series includes online fault diagnosis and direct protection for common electrical and thermal fault conditions.

Q5: What environments are suitable for these drivers?
Engineered for industrial and energy applications, SGD Series drives are designed for robust performance in both factory and energy infrastructure environments where medium‑voltage motor control is required.
