MP-MIS Series 800/799W I 2-in-1 Microinverter-7875

Compact Dual‑MPPT Solar Power Solution

The China Moneypro MIS Series 2‑in‑1 microinverter is designed for balcony and residential rooftop solar systems, combining high performance with a compact, plug‑and‑play design. Featuring dual MPPT tracking and broad module compatibility, it maximizes energy harvest from your PV panels. Advanced Wi‑Fi Mesh networking allows parallel connection of multiple units without a separate gateway, making installation faster, simpler, and more reliable.

High Yield & Precision Tracking

Optimize Energy from Every Panel

• 2 independent MPPT trackers deliver module‑level power optimization.

• 18 A max. DC input current per MPPT supports larger, high‑current PV modules.

• Low startup voltage — just 15 V for earlier morning and later evening power production.

• Max. conversion efficiency ~96.4 % for superior energy capture.

Benefits:

• Enhanced daily energy yield, even under varied irradiance conditions.

• Flexible panel configurations support a wide range of residential modules.

• Precision tracking reduces power loss from shading or mismatch.

Smart Operation & Networking

Easy Setup & Reliable Communication

• Plug‑and‑play installation for quick and hassle‑free setup.

• Advanced Wi‑Fi Mesh networking enables parallel connection of multiple inverters without a central gateway.

• Built‑in connectivity makes expansion and monitoring seamless.

Advantages:

• Faster system commissioning.

• Stable inverter communication across rooftop arrays.

• Supports larger multi‑unit installations with ease.

Robust Safety & Weather Protection

Built‑In Protection for Peace of Mind

• Rapid shutdown function cuts power in emergencies for enhanced safety.

• AC rapid discharge drops voltage to safe levels within 100 ms after disconnection.

• Three‑level lightning protection and grounding on the AC side for stable operation under grid disturbances.

• IP67 ingress protection ensures resistance versus dust, rain, and outdoor conditions.

Benefits:

• Safety features protect both people and equipment.

• Durable design suitable for various outdoor environments.

• Peace of mind with rugged electrical protections.

Why Choose China Moneypro MIS 2‑in‑1?

• Dual MPPT Precision: Independent tracking for two panel strings improves energy capture.

• Easy Installation: Plug‑and‑play design streamlines setup with minimal tools required.

• Low Startup Voltage: Generating power even in less favorable solar conditions.

• Reliable Networking: Wi‑Fi Mesh reduces complexity in multi‑unit systems.

• Strong Safety: Rapid shutdown, lightning protection, and IP67 durability.

Key Specifications

• Max. DC Input Voltage: 60 V

• Max. DC Input Current: 2 × 18 A

• MPP Trackers / Inputs per MPPT: 2 / 1

• Nominal Output Voltage: 220/230/240 V (L / N / PE)

• Max. Efficiency: ~96.4 %

• Startup Voltage: 15 V

• Ingress Protection: IP67

• Weight: ~3.4 kg

Typical Applications

• Balcony PV Systems: Ideal for compact clean energy setups.

• Residential Rooftops: Efficient conversion for homes with two string configurations.

• Multi‑Microinverter Arrays: Wi‑Fi Mesh networking supports parallel units.

• Outdoor Installations: IP67 protection for exposure to weather.

FAQ – Common Questions

Q1: What makes the MIS 2‑in‑1 different from standard microinverters?
It features dual MPPT trackers and Wi‑Fi Mesh networking, improving energy capture and simplifying parallel installation.

Q2: Can it operate in low light?
Yes — with a low start‑up voltage of just 15 V, it begins generating earlier in the morning and later in the evening.

Q3: How does the Wi‑Fi Mesh help?
Advanced Wi‑Fi Mesh self‑organizing networking connects multiple units without a central gateway.

Q4: Is it safe for outdoor use?
With IP67 protection and built‑in rapid shutdown and lightning safety features, it’s designed for outdoor reliability.

Q5: What panel configurations are supported?
The dual MPPT architecture supports two independent string inputs with up to 18 A per MPPT.
